Crydom DRA3R48B2
- Mfg. Part Number
- DRA3R48B2
- Manufacturer
- Crydom
- Product Category
- Solid State Relays
- Brief Description
- RELAY CONTACT 3PH REV 480VAC 2A
- Datasheet Download
- DRA3R48B2.pdf
Availability of DRA3R48B2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 141.19000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DRA3R48B2, we specialize in Crydom all series electronic components. DRA3R48B2 can be shipped within 24 hours after order. If you have any demands for DRA3R48B2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DRA3R48B2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DRA3R48B2
| Internal Part Number | EIS-DRA3R48B2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Declaration of Conformity | |
| 3D Model | DRA3R Series, AC.satDRA3R Series, AC.dwgDRA3R Series, AC.stp | |
| Standard Package | 10 | |
| Category | Relays | |
| Family | Solid State Relays | |
| Series | DRA3R | |
| Packaging | Bulk | |
| Circuit | 3PST (3 Form A) | |
| Output Type | AC | |
| On-State Resistance | - | |
| Load Current | 2.4A | |
| Voltage - Input | 90 ~ 140VAC | |
| Voltage - Load | 48 ~ 510 V | |
| Mounting Type | DIN Rail | |
| Termination Style | Screw Terminal | |
| Package / Case | Module | |
| Supplier Device Package | - | |
| Relay Type | Contactor | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DRA3R48B2 | |
| Related Links | DRA3, DRA3R48B2 Datasheet, Crydom Distributor | |
DRA3R48B2 Details Description
