Texas Instruments DRV5013ADQLPGM
- Mfg. Part Number
- DRV5013ADQLPGM
- Manufacturer
- Texas Instruments
- Product Category
- Magnetic Sensors - Hall Effect, Digital Switch, Linear, Compass (ICs)
- Brief Description
- IC HALL SENSOR DGTL SW TO-92
- Datasheet Download
- DRV5013ADQLPGM.pdf
Availability of DRV5013ADQLPGM
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.29375
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DRV5013ADQLPGM, we specialize in Texas Instruments all series electronic components. DRV5013ADQLPGM can be shipped within 24 hours after order. If you have any demands for DRV5013ADQLPGM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DRV5013ADQLPGM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DRV5013ADQLPGM
| Internal Part Number | EIS-DRV5013ADQLPGM | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Understanding Hall Effect Sensor Datasheets | |
| Manufacturer Product Page | DRV5013ADQLPGM Specifications | |
| Standard Package | 3,000 | |
| Category | Sensors, Transducers | |
| Family | Magnetic Sensors - Hall Effect, Digital Switch, Linear, Compass (ICs) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Sensing Range | 2.7mT Trip, -2.7mT Release | |
| Type | Bipolar Latch | |
| Voltage - Supply | 2.5 V ~ 38 V | |
| Current - Supply | 3.5mA | |
| Current - Output (Max) | 30mA | |
| Output Type | Open Drain | |
| Features | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) | |
| Supplier Device Package | TO-92-3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DRV5013ADQLPGM | |
| Related Links | DRV5013, DRV5013ADQLPGM Datasheet, Texas Instruments Distributor | |
DRV5013ADQLPGM Details Description
