Maxim Integrated DS3151NB1
- Mfg. Part Number
- DS3151NB1
- Manufacturer
- Maxim Integrated
- Product Category
- Interface - Telecom
- Brief Description
- IC LIU SGL DS3/E3/STS-1 144CSBGA
- Datasheet Download
- DS3151NB1.pdf
Availability of DS3151NB1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DS3151NB1, we specialize in Maxim Integrated all series electronic components. DS3151NB1 can be shipped within 24 hours after order. If you have any demands for DS3151NB1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DS3151NB1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DS3151NB1
| Internal Part Number | EIS-DS3151NB1 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | T1/E1 and T3/E3 Transformer Selection Guide Pulse Template Measurement T3/E3/STS-1 LIU Secondary Surge Protection Design Modifying the E3 Template Compliance of the DS3150, DS315x and DS325x Redundancy Protection for T3/E3/STS-1 Networks Modifying the pulse shape of DS315x using Test Registers HFTA-09.0: T3/E3/STS-1 Fiber Optic Extension Interfacing the DS3144 Framer with the DS3154 Line Interface Unit (LIU) Connecting the Agere Ultramapper Device Family to Maxim T3/E3 LIUs Connecting the Agere Supermapper™ Device Family to Dallas T3 LIUs Guidelines for Laying Out T3 and E3 Network Interfaces Measuring Return Loss on T3/E3/STS-1 LIUs Configuring Maxim LIUs Without a Microcontroller Measuring Return Loss Using the Advantest R3132 Spectrum Analyzer | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Telecom | |
| Series | - | |
| Packaging | Tray | |
| Function | Line Interface Unit (LIU) | |
| Interface | * | |
| Number of Circuits | * | |
| Voltage - Supply | 3.135 V ~ 3.465 V | |
| Current - Supply | * | |
| Power (Watts) | * | |
| Operating Temperature | * | |
| Mounting Type | Surface Mount | |
| Package / Case | 144-BGA, CSPBGA | |
| Supplier Device Package | 144-TECSBGA (13x13) | |
| Includes | * | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DS3151NB1 | |
| Related Links | DS31, DS3151NB1 Datasheet, Maxim Integrated Distributor | |
