CUI Inc. DTS090220UDC-P13N
- Mfg. Part Number
- DTS090220UDC-P13N
- Manufacturer
- CUI Inc.
- Product Category
- AC DC Desktop, Wall Adapters
- Brief Description
- AC/DC DESKTOP ADAPTER 9V 20W
- Datasheet Download
- DTS090220UDC-P13N.pdf
Availability of DTS090220UDC-P13N
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DTS090220UDC-P13N, we specialize in CUI Inc. all series electronic components. DTS090220UDC-P13N can be shipped within 24 hours after order. If you have any demands for DTS090220UDC-P13N, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DTS090220UDC-P13N Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DTS090220UDC-P13N
| Internal Part Number | EIS-DTS090220UDC-P13N | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Desktop, Wall Adapters | |
| Series | - | |
| Region Utilized | - | |
| Form | Desktop (Class I) | |
| Input Type | Cord | |
| Voltage - Input | 90 ~ 264 VAC | |
| Voltage - Output | 9V | |
| Current - Output (Max) | 2.2A | |
| Power (Watts) | 20W | |
| No Load Power Consumption | - | |
| Polarization | Negative Center | |
| Applications | ITE (Commercial) | |
| Efficiency | 65% | |
| Operating Temperature | 10°C ~ 40°C | |
| Output Connector | Barrel Plug, 1.7mm I.D. x 4.0mm O.D. x 9.5mm | |
| Size / Dimension | 4.33" L x 2.36" W x 1.34" H (110.0mm x 60.0mm x 34.0mm) | |
| Approvals | - | |
| Power (Watts) - Max | 20W | |
| Input Connector | IEC 320-C8 | |
| Cord Length | 72" (1.83m) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DTS090220UDC-P13N | |
| Related Links | DTS09022, DTS090220UDC-P13N Datasheet, CUI Inc. Distributor | |
DTS090220UDC-P13N Details Description
