TE Connectivity Deutsch Connectors DTS20W11-5SD
- Mfg. Part Number
- DTS20W11-5SD
- Manufacturer
- TE Connectivity Deutsch Connectors
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 5POS FLANGE W/SKT
- Datasheet Download
- DTS20W11-5SD.pdf
Availability of DTS20W11-5SD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 52.00780
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DTS20W11-5SD, we specialize in TE Connectivity Deutsch Connectors all series electronic components. DTS20W11-5SD can be shipped within 24 hours after order. If you have any demands for DTS20W11-5SD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DTS20W11-5SD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DTS20W11-5SD
| Internal Part Number | EIS-DTS20W11-5SD | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-DTL-38999 Series III, DTS | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 5 | |
| Shell Size - Insert | 11-5 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Flange | |
| Termination | Crimp | |
| Fastening Type | Threaded | |
| Orientation | D | |
| Ingress Protection | Environment Resistant | |
| Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated | |
| Contact Finish | Gold | |
| Features | Shielded | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Current Rating | 7.5A | |
| Voltage - Rated | - | |
| Operating Temperature | -65°C ~ 175°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DTS20W11-5SD | |
| Related Links | DTS20W, DTS20W11-5SD Datasheet, TE Connectivity Deutsch Connectors Distributor | |
DTS20W11-5SD Details Description
