TE Connectivity Deutsch Connectors DTS24W17-99BA
- Mfg. Part Number
- DTS24W17-99BA
- Manufacturer
- TE Connectivity Deutsch Connectors
- Product Category
- Circular Connectors - Housings
- Brief Description
- CONN HSG RCPT JAM NUT 23POS SKT
- Datasheet Download
- DTS24W17-99BA.pdf
Availability of DTS24W17-99BA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 53.41180
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DTS24W17-99BA, we specialize in TE Connectivity Deutsch Connectors all series electronic components. DTS24W17-99BA can be shipped within 24 hours after order. If you have any demands for DTS24W17-99BA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DTS24W17-99BA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DTS24W17-99BA
| Internal Part Number | EIS-DTS24W17-99BA | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors - Housings | |
| Series | MIL-DTL-38999 Series III, DTS | |
| Packaging | Bulk | |
| Connector Type | Receptacle for Female Contacts | |
| Number of Positions | 23 | |
| Shell Size - Insert | 17-99 | |
| Shell Size, MIL | - | |
| Contact Type | Crimp | |
| Contact Size | 16 (2), 20 (21) | |
| Mounting Type | Panel Mount, Bulkhead - Front Side Nut | |
| Fastening Type | Threaded | |
| Orientation | A | |
| Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated | |
| Ingress Protection | Environment Resistant | |
| Features | Shielded | |
| Note | Contacts Not Provided | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DTS24W17-99BA | |
| Related Links | DTS24W, DTS24W17-99BA Datasheet, TE Connectivity Deutsch Connectors Distributor | |
DTS24W17-99BA Details Description
