Panasonic Electronic Components DZ2J02700L
- Mfg. Part Number
- DZ2J02700L
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 2.7V 200MW SMINI2
- Datasheet Download
- DZ2J02700L.pdf
Availability of DZ2J02700L
Available Quantity
8020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.05938
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DZ2J02700L, we specialize in Panasonic Electronic Components all series electronic components. DZ2J02700L can be shipped within 24 hours after order. If you have any demands for DZ2J02700L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DZ2J02700L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DZ2J02700L
| Internal Part Number | EIS-DZ2J02700L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Zener Diodes | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Voltage - Zener (Nom) (Vz) | 2.7V | |
| Tolerance | ±5% | |
| Power - Max | 200mW | |
| Impedance (Max) (Zzt) | 110 Ohm | |
| Current - Reverse Leakage @ Vr | 120µA @ 1V | |
| Voltage - Forward (Vf) (Max) @ If | 1V @ 10mA | |
| Operating Temperature | - | |
| Mounting Type | Surface Mount | |
| Package / Case | SC-90, SOD-323F | |
| Supplier Device Package | SMini2-F5-B | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DZ2J02700L | |
| Related Links | DZ2J0, DZ2J02700L Datasheet, Panasonic Electronic Components Distributor | |
