Everlight Electronics Co Ltd EAPL2214YA2
- Mfg. Part Number
- EAPL2214YA2
- Manufacturer
- Everlight Electronics Co Ltd
- Product Category
- LED Indication - Discrete
- Brief Description
- LED YELLOW CLEAR 2SMD
- Datasheet Download
- EAPL2214YA2.pdf
Availability of EAPL2214YA2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.19600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EAPL2214YA2, we specialize in Everlight Electronics Co Ltd all series electronic components. EAPL2214YA2 can be shipped within 24 hours after order. If you have any demands for EAPL2214YA2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EAPL2214YA2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EAPL2214YA2
| Internal Part Number | EIS-EAPL2214YA2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 6 (Time on Label) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Optoelectronics | |
| Family | LED Indication - Discrete | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Color | Yellow | |
| Lens Color | Colorless | |
| Lens Transparency | Clear | |
| Millicandela Rating | 183mcd | |
| Lens Style/Size | Oval with Flat Top, 1.70mm x 1.10mm | |
| Voltage - Forward (Vf) (Typ) | 2.05V | |
| Current - Test | 20mA | |
| Viewing Angle | 120° | |
| Mounting Type | Surface Mount | |
| Wavelength - Dominant | 590nm | |
| Wavelength - Peak | 591nm | |
| Features | - | |
| Package / Case | 2-SMD, J-Lead | |
| Supplier Device Package | 2-SMD | |
| Size / Dimension | 2.20mm L x 1.40mm W | |
| Height (Max) | 1.40mm | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EAPL2214YA2 | |
| Related Links | EAPL2, EAPL2214YA2 Datasheet, Everlight Electronics Co Ltd Distributor | |
