Vishay/Dale EB83-S0C1560W
- Mfg. Part Number
- EB83-S0C1560W
- Manufacturer
- Vishay/Dale
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CONN EDGEBOARD DUAL 30POS 5A
- Datasheet Download
- EB83-S0C1560W.pdf
Availability of EB83-S0C1560W
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 16.06500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EB83-S0C1560W, we specialize in Vishay/Dale all series electronic components. EB83-S0C1560W can be shipped within 24 hours after order. If you have any demands for EB83-S0C1560W, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EB83-S0C1560W Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EB83-S0C1560W
| Internal Part Number | EIS-EB83-S0C1560W | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | EB8 | |
| Packaging | Bulk | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 15 | |
| Number of Positions | 30 | |
| Card Thickness | 0.054" ~ 0.071" (1.37mm ~ 1.80mm) | |
| Number of Rows | 2 | |
| Pitch | 0.156" (3.96mm) | |
| Features | - | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Contact Type | Loop Bellows | |
| Color | Black | |
| Flange Feature | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Material - Insulation | Polyester, Glass Filled | |
| Read Out | Dual | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EB83-S0C1560W | |
| Related Links | EB83-S, EB83-S0C1560W Datasheet, Vishay/Dale Distributor | |
EB83-S0C1560W Details Description
