Panasonic Electronic Components ECJ-0EC1H560J
.jpg)
- Mfg. Part Number
- ECJ-0EC1H560J
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 56PF 50V NP0 0402
- Datasheet Download
- ECJ-0EC1H560J.pdf
Availability of ECJ-0EC1H560J
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ECJ-0EC1H560J, we specialize in Panasonic Electronic Components all series electronic components. ECJ-0EC1H560J can be shipped within 24 hours after order. If you have any demands for ECJ-0EC1H560J, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ECJ-0EC1H560J Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ECJ-0EC1H560J
| Internal Part Number | EIS-ECJ-0EC1H560J | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | MLCC/Arrays 14/Aug/2009 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 10,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | ECJ | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 56pF | |
| Tolerance | ±5% | |
| Voltage - Rated | 50V | |
| Temperature Coefficient | C0G, NP0 | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | 0402 (1005 Metric) | |
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.022" (0.55mm) | |
| Lead Spacing | - | |
| Features | - | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ECJ-0EC1H560J | |
| Related Links | ECJ-0E, ECJ-0EC1H560J Datasheet, Panasonic Electronic Components Distributor | |
ECJ-0EC1H560J Details Description
