XP Power ECL15UT03-S
- Mfg. Part Number
- ECL15UT03-S
- Manufacturer
- XP Power
- Product Category
- AC DC Converters
- Brief Description
- AC/DC CONVERTER 5V +/-15V 15W
- Datasheet Download
- ECL15UT03-S.pdf
Availability of ECL15UT03-S
Available Quantity
5025 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 41.33994
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ECL15UT03-S, we specialize in XP Power all series electronic components. ECL15UT03-S can be shipped within 24 hours after order. If you have any demands for ECL15UT03-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ECL15UT03-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ECL15UT03-S
| Internal Part Number | EIS-ECL15UT03-S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | ECL Series TUV Certificate ECL Series UL Certificate ECL Series CB Report | |
| RoHS Information | ECL Series Declaration of Conformity | |
| 3D Model | ECL15.igs | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Series | ECL | |
| Type | Enclosed | |
| Number of Outputs | 3 | |
| Voltage - Input | 85 ~ 264 VAC | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | 15V | |
| Voltage - Output 3 | -15V | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 2A, 150mA, 150mA | |
| Power (Watts) | 15W | |
| Applications | ITE (Commercial) | |
| Voltage - Isolation | 3kV (3000V) | |
| Efficiency | 81% | |
| Operating Temperature | -20°C ~ 70°C (With Derating) | |
| Features | Adjustable Output, DC Input Capable, Universal Input | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 3.30" L x 1.36" W x 1.04" H (84.0mm x 34.5mm x 26.4mm) | |
| Minimum Load Required | Yes | |
| Approvals | - | |
| Power (Watts) - Max | 15W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ECL15UT03-S | |
| Related Links | ECL15, ECL15UT03-S Datasheet, XP Power Distributor | |
