Crydom ED24F3R
- Mfg. Part Number
- ED24F3R
- Manufacturer
- Crydom
- Product Category
- Solid State Relays
- Brief Description
- RELAY SSR AC OUT 3A 35-72VDC
- Datasheet Download
- ED24F3R.pdf
Availability of ED24F3R
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 14.25000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ED24F3R, we specialize in Crydom all series electronic components. ED24F3R can be shipped within 24 hours after order. If you have any demands for ED24F3R, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ED24F3R Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ED24F3R
| Internal Part Number | EIS-ED24F3R | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Declaration of Conformity | |
| Product Training Modules | Solid State Relays | |
| Standard Package | 10 | |
| Category | Relays | |
| Family | Solid State Relays | |
| Series | LifePlus ED | |
| Packaging | Bulk | |
| Circuit | SPST-NO (1 Form A) | |
| Output Type | AC | |
| On-State Resistance | - | |
| Load Current | 3A | |
| Voltage - Input | 35 ~ 72VDC | |
| Voltage - Load | 24 ~ 280 V | |
| Mounting Type | Socketable | |
| Termination Style | Plug In, Quick Connect - 0.187" (4.7mm) | |
| Package / Case | Module | |
| Supplier Device Package | - | |
| Relay Type | Relay | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ED24F3R | |
| Related Links | ED2, ED24F3R Datasheet, Crydom Distributor | |
ED24F3R Details Description
