On-Shore Technology, Inc. EDSTLZ970/4-SW
- Mfg. Part Number
- EDSTLZ970/4-SW
- Manufacturer
- On-Shore Technology, Inc.
- Product Category
- Terminal Blocks - Headers, Plugs and Sockets
- Brief Description
- TERM BLOCK HDR 8POS R/A 5.08MM
- Datasheet Download
- EDSTLZ970/4-SW.pdf
Availability of EDSTLZ970/4-SW
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.10420
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EDSTLZ970/4-SW, we specialize in On-Shore Technology, Inc. all series electronic components. EDSTLZ970/4-SW can be shipped within 24 hours after order. If you have any demands for EDSTLZ970/4-SW, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EDSTLZ970/4-SW Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EDSTLZ970/4-SW
| Internal Part Number | EIS-EDSTLZ970/4-SW | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Headers, Plugs and Sockets | |
| Series | EDSTLZ970 | |
| Packaging | Bulk | |
| Type | Header, Male Pins, Shrouded (2 Side) | |
| Number of Positions | 8 | |
| Positions Per Level | 4 | |
| Number of Levels | 2 | |
| Pitch | 0.200" (5.08mm) | |
| Header Orientation | 90°, Right Angle | |
| Plug Wire Entry | - | |
| Termination Style | Solder | |
| Mounting Type | Through Hole | |
| Current - IEC | - | |
| Voltage - IEC | - | |
| Current - UL | 15A | |
| Voltage - UL | 300V | |
| Wire Gauge or Range - AWG | - | |
| Wire Gauge or Range - mm² | - | |
| Color | Green | |
| Operating Temperature | -30°C ~ 105°C | |
| Contact Mating Finish | - | |
| Features | Interlocking (Side) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EDSTLZ970/4-SW | |
| Related Links | EDSTLZ9, EDSTLZ970/4-SW Datasheet, On-Shore Technology, Inc. Distributor | |
EDSTLZ970/4-SW Details Description
