Silicon Labs EFM32HG309F64G-A-QFN24
- Mfg. Part Number
- EFM32HG309F64G-A-QFN24
- Manufacturer
- Silicon Labs
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 32BIT 64KB FLASH 24QFN
- Datasheet Download
- EFM32HG309F64G-A-QFN24.pdf
Availability of EFM32HG309F64G-A-QFN24
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.47258
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EFM32HG309F64G-A-QFN24, we specialize in Silicon Labs all series electronic components. EFM32HG309F64G-A-QFN24 can be shipped within 24 hours after order. If you have any demands for EFM32HG309F64G-A-QFN24, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EFM32HG309F64G-A-QFN24 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EFM32HG309F64G-A-QFN24
| Internal Part Number | EIS-EFM32HG309F64G-A-QFN24 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 6 (Time on Label) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Featured Product | Internet of Things | |
| Standard Package | 490 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | Happy Gecko | |
| Packaging | Tray | |
| Core Processor | ARM® Cortex®-M0+ | |
| Core Size | 32-Bit | |
| Speed | 25MHz | |
| Connectivity | I²C, IrDA, SmartCard, SPI, UART/USART, USB | |
| Peripherals | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT | |
| Number of I/O | 24 | |
| Program Memory Size | 64KB (64K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 8K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.98 V ~ 3.8 V | |
| Data Converters | A/D 2x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 24-VQFN Exposed Pad | |
| Supplier Device Package | 24-QFN (5x5) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EFM32HG309F64G-A-QFN24 | |
| Related Links | EFM32HG309F, EFM32HG309F64G-A-QFN24 Datasheet, Silicon Labs Distributor | |
EFM32HG309F64G-A-QFN24 Details Description
