Switchcraft Inc. EHSVHS2B
- Mfg. Part Number
- EHSVHS2B
- Manufacturer
- Switchcraft Inc.
- Product Category
- Circular Connectors - Adapters
- Brief Description
- CONN ADAPTER 4P-4P F-F PNL MNT
- Datasheet Download
- EHSVHS2B.pdf
Availability of EHSVHS2B
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EHSVHS2B, we specialize in Switchcraft Inc. all series electronic components. EHSVHS2B can be shipped within 24 hours after order. If you have any demands for EHSVHS2B, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EHSVHS2B Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EHSVHS2B
| Internal Part Number | EIS-EHSVHS2B | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors - Adapters | |
| Series | EH | |
| Packaging | Bulk | |
| Connector Style | Standard | |
| Convert From (Adapter End) | Female Sockets | |
| Convert To (Adapter End) | Female Sockets | |
| Shell Size - Insert (Convert From) | MiniDIN | |
| Shell Size - Insert (Convert To) | MiniDIN | |
| Number of Positions (Convert From) | 4 | |
| Number of Positions (Convert To) | 4 | |
| Mounting Type | Panel Mount | |
| Mounting Feature | Flange | |
| Fastening Type | Latch Lock | |
| Housing Material | Zinc Alloy | |
| Housing Color | Black | |
| Features | - | |
| Ingress Protection | - | |
| Shielding | Shielded | |
| Current Rating | - | |
| Voltage Rating | - | |
| Orientation (Convert From) | Keyed | |
| Orientation (Convert To) | Keyed | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EHSVHS2B | |
| Related Links | EHSV, EHSVHS2B Datasheet, Switchcraft Inc. Distributor | |
EHSVHS2B Details Description
