Everlight Electronics Co Ltd EL816(M)
- Mfg. Part Number
- EL816(M)
- Manufacturer
- Everlight Electronics Co Ltd
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Brief Description
- OPTOISOLTR 5KV TRANSISTOR 4-DIP
- Datasheet Download
- EL816(M).pdf
Availability of EL816(M)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.11088
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EL816(M), we specialize in Everlight Electronics Co Ltd all series electronic components. EL816(M) can be shipped within 24 hours after order. If you have any demands for EL816(M), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EL816(M) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EL816(M)
| Internal Part Number | EIS-EL816(M) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Isolators | |
| Family | Optoisolators - Transistor, Photovoltaic Output | |
| Series | - | |
| Packaging | Tube | |
| Number of Channels | 1 | |
| Voltage - Isolation | 5000Vrms | |
| Current Transfer Ratio (Min) | 50% @ 5mA | |
| Current Transfer Ratio (Max) | 600% @ 5mA | |
| Turn On / Turn Off Time (Typ) | - | |
| Rise / Fall Time (Typ) | 4µs, 3µs | |
| Input Type | DC | |
| Output Type | Transistor | |
| Voltage - Output (Max) | 80V | |
| Current - Output / Channel | 50mA | |
| Voltage - Forward (Vf) (Typ) | 1.2V | |
| Current - DC Forward (If) (Max) | 60mA | |
| Vce Saturation (Max) | 200mV | |
| Operating Temperature | -55°C ~ 110°C | |
| Mounting Type | Through Hole | |
| Package / Case | 4-DIP (0.400", 10.16mm) | |
| Supplier Device Package | 4-DIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EL816(M) | |
| Related Links | EL81, EL816(M) Datasheet, Everlight Electronics Co Ltd Distributor | |
