Panasonic Electronic Components ELC-12E471L
- Mfg. Part Number
- ELC-12E471L
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 470UH 640MA 440 MOHM
- Datasheet Download
- ELC-12E471L.pdf
Availability of ELC-12E471L
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.64944
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ELC-12E471L, we specialize in Panasonic Electronic Components all series electronic components. ELC-12E471L can be shipped within 24 hours after order. If you have any demands for ELC-12E471L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ELC-12E471L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ELC-12E471L
| Internal Part Number | EIS-ELC-12E471L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | 12E | |
| Packaging | Bulk | |
| Type | Wirewound | |
| Material - Core | - | |
| Inductance | 470µH | |
| Tolerance | ±10% | |
| Current Rating | 640mA | |
| Current - Saturation | - | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 440 mOhm | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | - | |
| Frequency - Test | 10kHz | |
| Mounting Type | Through Hole | |
| Package / Case | Radial | |
| Size / Dimension | 0.512" Dia (13.00mm) | |
| Height - Seated (Max) | 0.728" (18.50mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ELC-12E471L | |
| Related Links | ELC-1, ELC-12E471L Datasheet, Panasonic Electronic Components Distributor | |
