Amphenol Pcd ELFH06260
- Mfg. Part Number
- ELFH06260
- Manufacturer
- Amphenol Pcd
- Product Category
- Terminal Blocks - Headers, Plugs and Sockets
- Brief Description
- TERM BLOCK HDR 6POS VERT 5.08MM
- Datasheet Download
- ELFH06260.pdf
Availability of ELFH06260
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.04000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ELFH06260, we specialize in Amphenol Pcd all series electronic components. ELFH06260 can be shipped within 24 hours after order. If you have any demands for ELFH06260, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ELFH06260 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ELFH06260
| Internal Part Number | EIS-ELFH06260 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Headers, Plugs and Sockets | |
| Series | ELFH | |
| Packaging | Tray | |
| Type | Header, Male Pins, Shrouded (2 Side) | |
| Number of Positions | 6 | |
| Positions Per Level | 6 | |
| Number of Levels | 1 | |
| Pitch | 0.200" (5.08mm) | |
| Header Orientation | Vertical | |
| Plug Wire Entry | - | |
| Termination Style | Solder | |
| Mounting Type | Through Hole | |
| Current - IEC | - | |
| Voltage - IEC | - | |
| Current - UL | 15A | |
| Voltage - UL | 300V | |
| Wire Gauge or Range - AWG | - | |
| Wire Gauge or Range - mm² | - | |
| Color | Black | |
| Operating Temperature | -40°C ~ 105°C | |
| Contact Mating Finish | Tin | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ELFH06260 | |
| Related Links | ELFH, ELFH06260 Datasheet, Amphenol Pcd Distributor | |
ELFH06260 Details Description
