Amphenol Pcd ELFH16220
- Mfg. Part Number
- ELFH16220
- Manufacturer
- Amphenol Pcd
- Product Category
- Terminal Blocks - Headers, Plugs and Sockets
- Brief Description
- TERM BLOCK HDR 16POS R/A 5.08MM
- Datasheet Download
- ELFH16220.pdf
Availability of ELFH16220
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.25000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ELFH16220, we specialize in Amphenol Pcd all series electronic components. ELFH16220 can be shipped within 24 hours after order. If you have any demands for ELFH16220, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ELFH16220 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ELFH16220
| Internal Part Number | EIS-ELFH16220 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Headers, Plugs and Sockets | |
| Series | ELFH | |
| Packaging | Tray | |
| Type | Header, Male Pins, Shrouded (2 Side) | |
| Number of Positions | 16 | |
| Positions Per Level | 16 | |
| Number of Levels | 1 | |
| Pitch | 0.200" (5.08mm) | |
| Header Orientation | 90°, Right Angle | |
| Plug Wire Entry | - | |
| Termination Style | Solder | |
| Mounting Type | Through Hole | |
| Current - IEC | - | |
| Voltage - IEC | - | |
| Current - UL | 15A | |
| Voltage - UL | 300V | |
| Wire Gauge or Range - AWG | - | |
| Wire Gauge or Range - mm² | - | |
| Color | Black | |
| Operating Temperature | -40°C ~ 105°C | |
| Contact Mating Finish | Tin | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ELFH16220 | |
| Related Links | ELFH, ELFH16220 Datasheet, Amphenol Pcd Distributor | |
ELFH16220 Details Description
