Panasonic Electronic Components ELT-5KT150LB
- Mfg. Part Number
- ELT-5KT150LB
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 15UH 510MA 580 MOHM
- Datasheet Download
- ELT-5KT150LB.pdf
Availability of ELT-5KT150LB
Available Quantity
15020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.37008
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ELT-5KT150LB, we specialize in Panasonic Electronic Components all series electronic components. ELT-5KT150LB can be shipped within 24 hours after order. If you have any demands for ELT-5KT150LB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ELT-5KT150LB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ELT-5KT150LB
| Internal Part Number | EIS-ELT-5KT150LB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 5,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | 5KT | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | - | |
| Inductance | 15µH | |
| Tolerance | ±15% | |
| Current Rating | 510mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 580 mOhm | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | - | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.228" L x 0.204" W (5.80mm x 5.20mm) | |
| Height - Seated (Max) | 0.047" (1.20mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ELT-5KT150LB | |
| Related Links | ELT-5K, ELT-5KT150LB Datasheet, Panasonic Electronic Components Distributor | |
ELT-5KT150LB Details Description
