Alt EPM570GF256C4N
- Mfg. Part Number
- EPM570GF256C4N
- Manufacturer
- Alt
- Product Category
- Embedded - CPLDs (Complex Programmable Logic Devices)
- Brief Description
- IC CPLD 440MC 5.4NS 256FBGA
- Datasheet Download
- EPM570GF256C4N.pdf
Availability of EPM570GF256C4N
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 37.87000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EPM570GF256C4N, we specialize in Alt all series electronic components. EPM570GF256C4N can be shipped within 24 hours after order. If you have any demands for EPM570GF256C4N, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EPM570GF256C4N Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EPM570GF256C4N
| Internal Part Number | EIS-EPM570GF256C4N | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 90 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - CPLDs (Complex Programmable Logic Devices) | |
| Series | MAX® II | |
| Packaging | Tray | |
| Programmable Type | In System Programmable | |
| Delay Time tpd(1) Max | 5.4ns | |
| Voltage Supply - Internal | 1.71 V ~ 1.89 V | |
| Number of Logic Elements/Blocks | 570 | |
| Number of Macrocells | 440 | |
| Number of Gates | - | |
| Number of I/O | 160 | |
| Operating Temperature | 0°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 256-BGA | |
| Supplier Device Package | 256-FBGA (17x17) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EPM570GF256C4N | |
| Related Links | EPM570G, EPM570GF256C4N Datasheet, Alt Distributor | |
EPM570GF256C4N Details Description
