API Delevan ER1641-272KP
- Mfg. Part Number
- ER1641-272KP
- Manufacturer
- API Delevan
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.7UH 535MA 280 MOHM
- Datasheet Download
- ER1641-272KP.pdf
Availability of ER1641-272KP
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.32640
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ER1641-272KP, we specialize in API Delevan all series electronic components. ER1641-272KP can be shipped within 24 hours after order. If you have any demands for ER1641-272KP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ER1641-272KP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ER1641-272KP
| Internal Part Number | EIS-ER1641-272KP | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | ER1641 | |
| Packaging | Bulk | |
| Type | Molded | |
| Material - Core | Iron | |
| Inductance | 2.7µH | |
| Tolerance | ±10% | |
| Current Rating | 535mA | |
| Current - Saturation | - | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 280 mOhm Max | |
| Q @ Freq | 44 @ 7.9MHz | |
| Frequency - Self Resonant | 92MHz | |
| Operating Temperature | -55°C ~ 105°C | |
| Frequency - Test | 7.9MHz | |
| Mounting Type | Through Hole | |
| Package / Case | Axial | |
| Size / Dimension | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | |
| Height - Seated (Max) | - | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ER1641-272KP | |
| Related Links | ER1641, ER1641-272KP Datasheet, API Delevan Distributor | |
ER1641-272KP Details Description
