Panasonic Electronic Components ERJ-2RHD1000X

ERJ-2RHD1000X picture photo
Mfg. Part Number
ERJ-2RHD1000X
Manufacturer
Product Category
Chip Resistor - Surface Mount
Brief Description
RES SMD 100 OHM 0.5% 1/16W 0402
Datasheet Download
ERJ-2RHD1000X.pdf
Availability of ERJ-2RHD1000X

Available Quantity

46019 Pieces

Can ship today


Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks

Marketing Price
$ 0.01365
Our Price
Quote by Email

QUANTITY



EIS Components is the stocking Distributor of ERJ-2RHD1000X, we specialize in Panasonic Electronic Components all series electronic components. ERJ-2RHD1000X can be shipped within 24 hours after order. If you have any demands for ERJ-2RHD1000X, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
ERJ-2RHD1000X Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of ERJ-2RHD1000X
Internal Part NumberEIS-ERJ-2RHD1000X
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
Standard Package1
Category Resistors
FamilyChip Resistor - Surface Mount
SeriesERJ
PackagingDigi-Reel®
Resistance (Ohms)100
Tolerance±0.5%
Power (Watts)0.063W, 1/16W
CompositionThick Film
FeaturesAutomotive AEC-Q200
Temperature Coefficient±50ppm/°C
Operating Temperature-55°C ~ 125°C
Package / Case0402 (1005 Metric)
Supplier Device Package0402
Size / Dimension0.039" L x 0.020" W (1.00mm x 0.50mm)
Height0.016" (0.40mm)
Number of Terminations2
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)ERJ-2RHD1000X
Related LinksERJ-2R, ERJ-2RHD1000X Datasheet, Panasonic Electronic Components Distributor
ERJ-2RHD1000X Details Description
