ST ESDALC5-1BT2
- Mfg. Part Number
- ESDALC5-1BT2
- Manufacturer
- ST
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 5VWM SOD882T
- Datasheet Download
- ESDALC5-1BT2.pdf
Availability of ESDALC5-1BT2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.10332
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ESDALC5-1BT2, we specialize in ST all series electronic components. ESDALC5-1BT2 can be shipped within 24 hours after order. If you have any demands for ESDALC5-1BT2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ESDALC5-1BT2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ESDALC5-1BT2
| Internal Part Number | EIS-ESDALC5-1BT2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | ESDALC5-1BT2 View All Specifications ESDALC5-1BT2 View All Specifications | |
| Standard Package | 12,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | ESDA, TRANSIL™ | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | - | |
| Bidirectional Channels | 1 | |
| Voltage - Reverse Standoff (Typ) | 5V | |
| Voltage - Breakdown (Min) | 5.8V | |
| Voltage - Clamping (Max) @ Ipp | - | |
| Current - Peak Pulse (10/1000µs) | - | |
| Power - Peak Pulse | 150W | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | 26pF @ 1MHz | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | SOD-882 | |
| Supplier Device Package | SOD-882T | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ESDALC5-1BT2 | |
| Related Links | ESDALC, ESDALC5-1BT2 Datasheet, ST Distributor | |
ESDALC5-1BT2 Details Description
