Panasonic Electronic Components EVP-AJAE1A
- Mfg. Part Number
- EVP-AJAE1A
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Tactile Switches
- Brief Description
- SWITCH TACTILE SPDT 0.02A 15V
- Datasheet Download
- EVP-AJAE1A.pdf
Availability of EVP-AJAE1A
Available Quantity
10020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.70551
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EVP-AJAE1A, we specialize in Panasonic Electronic Components all series electronic components. EVP-AJAE1A can be shipped within 24 hours after order. If you have any demands for EVP-AJAE1A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EVP-AJAE1A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EVP-AJAE1A
| Internal Part Number | EIS-EVP-AJAE1A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | EVPAJ Series.stp | |
| Standard Package | 5,000 | |
| Category | Switches | |
| Family | Tactile Switches | |
| Series | EVPAJ | |
| Packaging | Tape & Reel (TR) | |
| Circuit | SPDT | |
| Switch Function | Off-Mom-Mom | |
| Contact Rating @ Voltage | 0.02A @ 15VDC | |
| Actuator Type | Rectangular Button | |
| Mounting Type | Surface Mount, Right Angle | |
| Actuator Height off PCB, from Pins | - | |
| Actuator Orientation | Side Actuated | |
| Termination Style | Gull Wing | |
| Outline | 4.70mm x 3.50mm | |
| Illumination | Non-Illuminated | |
| Illumination Voltage (Nominal) | - | |
| Illumination Type, Color | - | |
| Operating Force | 160/260gf | |
| Ingress Protection | - | |
| Features | Grounding Pin | |
| Actuator Material | - | |
| Switch Travel | 0.15mm, 0.40mm | |
| Mechanical Life | 100,000 Cycles | |
| Operating Temperature | -20°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EVP-AJAE1A | |
| Related Links | EVP-A, EVP-AJAE1A Datasheet, Panasonic Electronic Components Distributor | |
EVP-AJAE1A Details Description
