Panasonic Electronic Components EXB-2HV224JV
- Mfg. Part Number
- EXB-2HV224JV
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Resistor Networks, Arrays
- Brief Description
- RES ARRAY 8 RES 220K OHM 1506
- Datasheet Download
- EXB-2HV224JV.pdf
Availability of EXB-2HV224JV
Available Quantity
15020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.03188
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EXB-2HV224JV, we specialize in Panasonic Electronic Components all series electronic components. EXB-2HV224JV can be shipped within 24 hours after order. If you have any demands for EXB-2HV224JV, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EXB-2HV224JV Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EXB-2HV224JV
| Internal Part Number | EIS-EXB-2HV224JV | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 5,000 | |
| Category | Resistors | |
| Family | Resistor Networks, Arrays | |
| Series | EXB | |
| Packaging | Tape & Reel (TR) | |
| Circuit Type | Isolated | |
| Resistance (Ohms) | 220k | |
| Tolerance | ±5% | |
| Number of Resistors | 8 | |
| Number of Pins | 16 | |
| Power Per Element | 62.5mW | |
| Temperature Coefficient | ±200ppm/°C | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | Automotive AEC-Q200 | |
| Mounting Type | Surface Mount | |
| Package / Case | 1506, Convex, Long Side Terminals | |
| Supplier Device Package | 1506 | |
| Size / Dimension | 0.150" L x 0.063" W (3.80mm x 1.60mm) | |
| Height | 0.022" (0.55mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EXB-2HV224JV | |
| Related Links | EXB-2H, EXB-2HV224JV Datasheet, Panasonic Electronic Components Distributor | |
EXB-2HV224JV Details Description
