Panasonic Electronic Components EXC-24CG900U
- Mfg. Part Number
- EXC-24CG900U
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Common Mode Chokes
- Brief Description
- NOISE FILTER COM MODE 90 OHM
- Datasheet Download
- EXC-24CG900U.pdf
Availability of EXC-24CG900U
Available Quantity
45020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.26702
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EXC-24CG900U, we specialize in Panasonic Electronic Components all series electronic components. EXC-24CG900U can be shipped within 24 hours after order. If you have any demands for EXC-24CG900U, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EXC-24CG900U Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EXC-24CG900U
| Internal Part Number | EIS-EXC-24CG900U | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 5,000 | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Series | EXC24CG | |
| Packaging | Tape & Reel (TR) | |
| Filter Type | Data, Signal Line | |
| Number of Lines | 2 | |
| Inductance | - | |
| Current | 100mA | |
| DC Resistance (DCR) | 3 Ohm Max | |
| Impedance | 90 Ohm | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.049" L x 0.039" W (1.25mm x 1.00mm) | |
| Height (Max) | 0.024" (0.60mm) | |
| Package / Case | 0504 (1210 Metric), 4 Lead | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EXC-24CG900U | |
| Related Links | EXC-24, EXC-24CG900U Datasheet, Panasonic Electronic Components Distributor | |
EXC-24CG900U Details Description
