Hirose Electric Co Ltd FH12A-15S-0.5SH(55)
- Mfg. Part Number
- FH12A-15S-0.5SH(55)
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN FFC TOP 15POS 0.50MM R/A
- Datasheet Download
- FH12A-15S-0.5SH(55).pdf
Availability of FH12A-15S-0.5SH(55)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.75400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FH12A-15S-0.5SH(55), we specialize in Hirose Electric Co Ltd all series electronic components. FH12A-15S-0.5SH(55) can be shipped within 24 hours after order. If you have any demands for FH12A-15S-0.5SH(55), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FH12A-15S-0.5SH(55) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FH12A-15S-0.5SH(55)
| Internal Part Number | EIS-FH12A-15S-0.5SH(55) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | FH12 - 1mm & 0.5mm FPC/FFC connectors | |
| Featured Product | FH12 Series | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,000 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | FH12 | |
| Packaging | Tape & Reel (TR) | |
| Flat Flex Type | FFC, FPC | |
| Mounting Type | Surface Mount, Right Angle | |
| Connector/Contact Type | Contacts, Top | |
| Number of Positions | 15 | |
| Pitch | 0.020" (0.50mm) | |
| Termination | Solder | |
| FFC, FCB Thickness | 0.30mm | |
| Height Above Board | 0.079" (2.00mm) | |
| Locking Feature | Flip Lock | |
| Cable End Type | Straight | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Housing Material | Polyamide (PA), Nylon | |
| Actuator Material | Polyphenylene Sulfide (PPS) | |
| Features | Zero Insertion Force (ZIF) | |
| Voltage Rating | 50V | |
| Operating Temperature | -40°C ~ 85°C | |
| Material Flammability Rating | UL94 V-0 | |
| Current Rating | 0.5A | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FH12A-15S-0.5SH(55) | |
| Related Links | FH12A-15S, FH12A-15S-0.5SH(55) Datasheet, Hirose Electric Co Ltd Distributor | |
FH12A-15S-0.5SH(55) Details Description
