Hirose Electric Co Ltd FH35C-21S-0.3SHW(99)

FH35C-21S-0.3SHW(99) picture photo
Mfg. Part Number
FH35C-21S-0.3SHW(99)
Manufacturer
Product Category
FFC, FPC (Flat Flexible) Connectors
Brief Description
CONN FPC 21POS 0.30MM R/A
Datasheet Download
FH35C-21S-0.3SHW(99).pdf
Availability of FH35C-21S-0.3SHW(99)

Available Quantity

5502 Pieces

Can ship today

Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks

Marketing Price
$ 1.86012
Our Price
Quote by Email

QUANTITY



EIS Components is the stocking Distributor of FH35C-21S-0.3SHW(99), we specialize in Hirose Electric Co Ltd all series electronic components. FH35C-21S-0.3SHW(99) can be shipped within 24 hours after order. If you have any demands for FH35C-21S-0.3SHW(99), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
FH35C-21S-0.3SHW(99) Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of FH35C-21S-0.3SHW(99)
Internal Part NumberEIS-FH35C-21S-0.3SHW(99)
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
Video FileTablet PC Connectors - Hirose
Featured ProductFH35C Series Connectors
Standard Package1
Category Connectors, Interconnects
FamilyFFC, FPC (Flat Flexible) Connectors
SeriesFH35C
PackagingCut Tape (CT)
Flat Flex TypeFPC
Mounting TypeSurface Mount, Right Angle
Connector/Contact TypeContacts, Top and Bottom
Number of Positions21
Pitch0.012" (0.30mm)
TerminationSolder
FFC, FCB Thickness0.20mm
Height Above Board0.036" (0.90mm)
Locking FeatureFlip Lock, Backlock
Cable End TypeTapered
Contact MaterialPhosphor Bronze
Contact FinishGold
Housing MaterialLiquid Crystal Polymer (LCP)
Actuator MaterialPolyamide (PA), Nylon
Features-
Voltage Rating30V
Operating Temperature-55°C ~ 85°C
Material Flammability RatingUL94 V-0
Current Rating0.2A
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)FH35C-21S-0.3SHW(99)
Related LinksFH35C-21S-, FH35C-21S-0.3SHW(99) Datasheet, Hirose Electric Co Ltd Distributor
FH35C-21S-0.3SHW(99) Details Description
