Schaffner EMC Inc. FN9244S1B-3-06
- Mfg. Part Number
- FN9244S1B-3-06
- Manufacturer
- Schaffner EMC Inc.
- Product Category
- Power Entry Connectors - Inlets, Outlets, Modules
- Brief Description
- FILTER SNAP-IN MED IEC INLET 3A
- Datasheet Download
- FN9244S1B-3-06.pdf
Availability of FN9244S1B-3-06
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.57300
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FN9244S1B-3-06, we specialize in Schaffner EMC Inc. all series electronic components. FN9244S1B-3-06 can be shipped within 24 hours after order. If you have any demands for FN9244S1B-3-06, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FN9244S1B-3-06 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FN9244S1B-3-06
| Internal Part Number | EIS-FN9244S1B-3-06 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | FN9244 IEC Inlet Filters | |
| Standard Package | 30 | |
| Category | Connectors, Interconnects | |
| Family | Power Entry Connectors - Inlets, Outlets, Modules | |
| Series | FN 9244 | |
| Packaging | Bulk | |
| Connector Style | IEC 320-C14 | |
| Connector Type | Receptacle, Male Blades | |
| Current - IEC | - | |
| Voltage - IEC | - | |
| Current - UL | 3A | |
| Voltage - UL | 250VAC | |
| Filter Type | Filtered (EMI, RFI) - Commercial, Medical | |
| Fuse | No | |
| Number of Positions | 3 | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination | Quick Connect - 0.250" (6.3mm) | |
| Switch Features | - | |
| Features | Bleed Resistor | |
| Fuse Holder, Drawer | - | |
| Panel Cutout Dimensions | Rectangular - 28.50mm x 21.90mm | |
| Panel Thickness | 0.028" ~ 0.059" (0.70mm ~ 1.50mm) | |
| Material Flammability Rating | UL94 V-2 | |
| Ingress Protection | IP40 | |
| Approvals | CQC, CSA, ENEC, UL | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FN9244S1B-3-06 | |
| Related Links | FN9244S, FN9244S1B-3-06 Datasheet, Schaffner EMC Inc. Distributor | |
FN9244S1B-3-06 Details Description
