Fairchild Semiconductor FQP10N60C
- Mfg. Part Number
- FQP10N60C
- Manufacturer
- Fairchild Semiconductor
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 600V 9.5A TO-220
- Datasheet Download
- FQP10N60C.pdf
Availability of FQP10N60C
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FQP10N60C, we specialize in Fairchild Semiconductor all series electronic components. FQP10N60C can be shipped within 24 hours after order. If you have any demands for FQP10N60C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FQP10N60C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FQP10N60C
| Internal Part Number | EIS-FQP10N60C | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | QFET® | |
| Packaging | Tube | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 600V | |
| Current - Continuous Drain (Id) @ 25°C | 9.5A (Tc) | |
| Rds On (Max) @ Id, Vgs | 730 mOhm @ 4.75A, 10V | |
| Vgs(th) (Max) @ Id | 4V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 57nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 2040pF @ 25V | |
| Power - Max | 156W | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 | |
| Supplier Device Package | TO-220 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FQP10N60C | |
| Related Links | FQP1, FQP10N60C Datasheet, Fairchild Semiconductor Distributor | |
FQP10N60C Details Description
