Fox Electronics FXO-HC535R-24
- Mfg. Part Number
- FXO-HC535R-24
- Manufacturer
- Fox Electronics
- Product Category
- Oscillators
- Brief Description
- OSC XO 24.000MHZ HCMOS SMD
- Datasheet Download
- FXO-HC535R-24.pdf
Availability of FXO-HC535R-24
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 17.08000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FXO-HC535R-24, we specialize in Fox Electronics all series electronic components. FXO-HC535R-24 can be shipped within 24 hours after order. If you have any demands for FXO-HC535R-24, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FXO-HC535R-24 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FXO-HC535R-24
| Internal Part Number | EIS-FXO-HC535R-24 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Crystals and Oscillators | |
| Family | Oscillators | |
| Series | XPRESSO™ FXO-HC53 | |
| Packaging | Cut Strip | |
| Type | XO (Standard) | |
| Frequency | 24MHz | |
| Function | Tri-State (Output Enable) | |
| Output | HCMOS | |
| Voltage - Supply | 3.3V | |
| Frequency Stability | ±50ppm | |
| Operating Temperature | -40°C ~ 85°C | |
| Current - Supply (Max) | 35mA | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.203" L x 0.132" W (5.15mm x 3.35mm) | |
| Height | 0.055" (1.40mm) | |
| Package / Case | 4-SMD, No Lead (DFN, LCC) | |
| Current - Supply (Disable) (Max) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FXO-HC535R-24 | |
| Related Links | FXO-HC, FXO-HC535R-24 Datasheet, Fox Electronics Distributor | |
