Omron G2RL-1A DC48
- Mfg. Part Number
- G2RL-1A DC48
- Manufacturer
- Omron
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY GEN PURPOSE SPST 12A 48V
- Datasheet Download
- G2RL-1A DC48.pdf
Availability of G2RL-1A DC48
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.70600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of G2RL-1A DC48, we specialize in Omron all series electronic components. G2RL-1A DC48 can be shipped within 24 hours after order. If you have any demands for G2RL-1A DC48, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- G2RL-1A DC48 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
G2RL-1A DC48
| Internal Part Number | EIS-G2RL-1A DC48 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| Standard Package | 20 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | G2RL | |
| Packaging | Tube | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 8.96mA | |
| Coil Voltage | 48VDC | |
| Contact Form | SPST-NO (1 Form A) | |
| Contact Rating (Current) | 12A | |
| Switching Voltage | 440VAC, 300VDC - Max | |
| Turn On Voltage (Max) | 33.6 VDC | |
| Turn Off Voltage (Min) | 4.8 VDC | |
| Operate Time | 15ms | |
| Release Time | 5ms | |
| Features | Insulation - Class B, Sealed - Flux Protection | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Contact Material | Silver Alloy, Cadmium Free | |
| Coil Power | 430 mW | |
| Coil Resistance | 5.36 kOhms | |
| Operating Temperature | -40°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | G2RL-1A DC48 | |
| Related Links | G2RL-1, G2RL-1A DC48 Datasheet, Omron Distributor | |
