Omron G3VM-81HR(TR)
- Mfg. Part Number
- G3VM-81HR(TR)
- Manufacturer
- Omron
- Product Category
- Solid State Relays
- Brief Description
- RELAY SSR SPST 80V 1.25A 6SOP
- Datasheet Download
- G3VM-81HR(TR).pdf
Availability of G3VM-81HR(TR)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 7.31069
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of G3VM-81HR(TR), we specialize in Omron all series electronic components. G3VM-81HR(TR) can be shipped within 24 hours after order. If you have any demands for G3VM-81HR(TR), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- G3VM-81HR(TR) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
G3VM-81HR(TR)
| Internal Part Number | EIS-G3VM-81HR(TR) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | SSR Design Considerations How to Read Date Codes | |
| Product Training Modules | Medical Solutions MOSFET Relays Overview | |
| Standard Package | 2,500 | |
| Category | Relays | |
| Family | Solid State Relays | |
| Series | G3VM | |
| Packaging | Tape & Reel (TR) | |
| Circuit | SPST-NO (1 Form A) | |
| Output Type | AC, DC | |
| On-State Resistance | 150 mOhm | |
| Load Current | 1.25A | |
| Voltage - Input | 1.15VDC | |
| Voltage - Load | 0 ~ 80 V | |
| Mounting Type | Surface Mount | |
| Termination Style | Gull Wing | |
| Package / Case | 6-SOP (0.173", 4.40mm) | |
| Supplier Device Package | 6-SOP | |
| Relay Type | Relay | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | G3VM-81HR(TR) | |
| Related Links | G3VM-8, G3VM-81HR(TR) Datasheet, Omron Distributor | |
G3VM-81HR(TR) Details Description
