Global Power Technologies Group GSXD080A020S1-D3
- Mfg. Part Number
- GSXD080A020S1-D3
- Manufacturer
- Global Power Technologies Group
- Product Category
- Diodes, Rectifiers - Arrays
- Brief Description
- DIODE 200V 80A SOT227
- Datasheet Download
- GSXD080A020S1-D3.pdf
Availability of GSXD080A020S1-D3
Available Quantity
5094 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.39840
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of GSXD080A020S1-D3, we specialize in Global Power Technologies Group all series electronic components. GSXD080A020S1-D3 can be shipped within 24 hours after order. If you have any demands for GSXD080A020S1-D3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- GSXD080A020S1-D3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
GSXD080A020S1-D3
| Internal Part Number | EIS-GSXD080A020S1-D3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 13 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Arrays | |
| Series | - | |
| Packaging | Box | |
| Diode Configuration | 2 Independent | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 200V | |
| Current - Average Rectified (Io) (per Diode) | 80A | |
| Voltage - Forward (Vf) (Max) @ If | 920mV @ 80A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 3mA @ 200V | |
| Mounting Type | Chassis Mount | |
| Package / Case | SOT-227-4, miniBLOC | |
| Supplier Device Package | SOT-227 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | GSXD080A020S1-D3 | |
| Related Links | GSXD080A, GSXD080A020S1-D3 Datasheet, Global Power Technologies Group Distributor | |
