Avago Technologies US, Inc. HBAT-540C-TR1G
- Mfg. Part Number
- HBAT-540C-TR1G
- Manufacturer
- Avago Technologies US, Inc.
- Product Category
- RF Diodes
- Brief Description
- DIODE SCHOTTKY 30V 430MA SOT-323
- Datasheet Download
- HBAT-540C-TR1G.pdf
Availability of HBAT-540C-TR1G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HBAT-540C-TR1G, we specialize in Avago Technologies US, Inc. all series electronic components. HBAT-540C-TR1G can be shipped within 24 hours after order. If you have any demands for HBAT-540C-TR1G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HBAT-540C-TR1G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HBAT-540C-TR1G
| Internal Part Number | EIS-HBAT-540C-TR1G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 03/Jul/2012 | |
| PCN Assembly/Origin | Alternate Assembly and Test Sources 15/May/2012 | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | RF Diodes | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Type | Schottky - 1 Pair Series Connection | |
| Voltage - Peak Reverse (Max) | 30V | |
| Current - Max | 430mA | |
| Capacitance @ Vr, F | - | |
| Resistance @ If, F | - | |
| Power Dissipation (Max) | 825mW | |
| Package / Case | SC-70, SOT-323 | |
| Supplier Device Package | SOT-323 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HBAT-540C-TR1G | |
| Related Links | HBAT-54, HBAT-540C-TR1G Datasheet, Avago Technologies US, Inc. Distributor | |
HBAT-540C-TR1G Details Description
