Panasonic Electric Works HC3-HTM-AC100V-F
- Mfg. Part Number
- HC3-HTM-AC100V-F
- Manufacturer
- Panasonic Electric Works
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY GEN PURPOSE 3PDT 7A 100V
- Datasheet Download
- HC3-HTM-AC100V-F.pdf
Availability of HC3-HTM-AC100V-F
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.52550
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HC3-HTM-AC100V-F, we specialize in Panasonic Electric Works all series electronic components. HC3-HTM-AC100V-F can be shipped within 24 hours after order. If you have any demands for HC3-HTM-AC100V-F, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HC3-HTM-AC100V-F Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HC3-HTM-AC100V-F
| Internal Part Number | EIS-HC3-HTM-AC100V-F | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | General Appl Guidelines Standards Chart How to Read Date Codes | |
| Standard Package | 1 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | HC | |
| Packaging | Bulk | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 13.2mA | |
| Coil Voltage | 100VAC | |
| Contact Form | 3PDT (3 Form C) | |
| Contact Rating (Current) | 7A | |
| Switching Voltage | 250VAC - Max | |
| Turn On Voltage (Max) | 80 VAC | |
| Turn Off Voltage (Min) | 30 VAC | |
| Operate Time | 20ms | |
| Release Time | 20ms | |
| Features | - | |
| Mounting Type | Chassis Mount | |
| Termination Style | Plug In | |
| Contact Material | Silver Alloy, Cadmium Free | |
| Coil Power | 1.2 VA | |
| Coil Resistance | - | |
| Operating Temperature | -50°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HC3-HTM-AC100V-F | |
| Related Links | HC3-HTM-, HC3-HTM-AC100V-F Datasheet, Panasonic Electric Works Distributor | |
HC3-HTM-AC100V-F Details Description
