Avago Technologies US, Inc. HCPL-2300-560E
- Mfg. Part Number
- HCPL-2300-560E
- Manufacturer
- Avago Technologies US, Inc.
- Product Category
- Optoisolators - Logic Output
- Brief Description
- OPTOISO 3.75KV OPEN COLL 8DIP GW
- Datasheet Download
- HCPL-2300-560E.pdf
Availability of HCPL-2300-560E
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.26950
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HCPL-2300-560E, we specialize in Avago Technologies US, Inc. all series electronic components. HCPL-2300-560E can be shipped within 24 hours after order. If you have any demands for HCPL-2300-560E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HCPL-2300-560E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HCPL-2300-560E
| Internal Part Number | EIS-HCPL-2300-560E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Mult Device Design Changes 10/Nov/2015 | |
| PCN Packaging | Multiple Devices Marking/Labeling 07/Aug/2013 Marking/Labeling Revision B 14/Jan/2014 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,000 | |
| Category | Isolators | |
| Family | Optoisolators - Logic Output | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Channels | 1 | |
| Inputs - Side 1/Side 2 | 1/0 | |
| Voltage - Isolation | 3750Vrms | |
| Common Mode Transient Immunity (Min) | 100V/µs | |
| Input Type | DC | |
| Output Type | Open Collector, Schottky Clamped | |
| Current - Output / Channel | 25mA | |
| Data Rate | 5MBd | |
| Propagation Delay tpLH / tpHL (Max) | 160ns, 200ns | |
| Rise / Fall Time (Typ) | 40ns, 20ns | |
| Voltage - Forward (Vf) (Typ) | 1.3V | |
| Current - DC Forward (If) (Max) | 5mA | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SMD, Gull Wing | |
| Supplier Device Package | 8-DIP Gull Wing | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HCPL-2300-560E | |
| Related Links | HCPL-23, HCPL-2300-560E Datasheet, Avago Technologies US, Inc. Distributor | |
