Crydom HD6025F-10
- Mfg. Part Number
- HD6025F-10
- Manufacturer
- Crydom
- Product Category
- Solid State Relays
- Brief Description
- RELAY SSR 25A 600VAC AC OUT PNL
- Datasheet Download
- HD6025F-10.pdf
Availability of HD6025F-10
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 55.40000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HD6025F-10, we specialize in Crydom all series electronic components. HD6025F-10 can be shipped within 24 hours after order. If you have any demands for HD6025F-10, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HD6025F-10 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HD6025F-10
| Internal Part Number | EIS-HD6025F-10 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Declaration of Conformity | |
| 3D Model | HA/HD Series.stpHA/HD Series.satHA/HD Series.dwg | |
| Standard Package | 20 | |
| Category | Relays | |
| Family | Solid State Relays | |
| Series | HD60 | |
| Packaging | Bulk | |
| Circuit | SPST-NO (1 Form A) | |
| Output Type | AC | |
| On-State Resistance | - | |
| Load Current | 25A | |
| Voltage - Input | 3 ~ 32VDC | |
| Voltage - Load | 48 ~ 660 V | |
| Mounting Type | Chassis Mount or Panel Mount | |
| Termination Style | Quick Connect - 0.187"/0.250" | |
| Package / Case | Hockey Puck | |
| Supplier Device Package | - | |
| Relay Type | Relay | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HD6025F-10 | |
| Related Links | HD602, HD6025F-10 Datasheet, Crydom Distributor | |
