TT Electronics/BI HM31-20050LLF
- Mfg. Part Number
- HM31-20050LLF
- Manufacturer
- TT Electronics/BI
- Product Category
- Current Sense Transformers
- Brief Description
- ENCAPSULATED CURRENT SENSE TRANS
- Datasheet Download
- HM31-20050LLF.pdf
Availability of HM31-20050LLF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.46720
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HM31-20050LLF, we specialize in TT Electronics/BI all series electronic components. HM31-20050LLF can be shipped within 24 hours after order. If you have any demands for HM31-20050LLF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HM31-20050LLF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HM31-20050LLF
| Internal Part Number | EIS-HM31-20050LLF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Cert. of Compliance | |
| Standard Package | 900 | |
| Category | Transformers | |
| Family | Current Sense Transformers | |
| Series | HM31 | |
| Turns Ratio - Primary:Secondary | 1 : 50 | |
| Frequency | - | |
| Inductance | 5mH | |
| Current Rating | 20A | |
| DC Resistance (DCR) | 700 mOhm Max | |
| E.T. | 330V µS | |
| Mounting Type | Through Hole | |
| Size / Dimension | 17.50mm L x 9.60mm W | |
| Height - Seated (Max) | 22.00mm | |
| Termination Style | PC Pin | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HM31-20050LLF | |
| Related Links | HM31-2, HM31-20050LLF Datasheet, TT Electronics/BI Distributor | |
