TT Electronics/BI HM33-10040LFTR
- Mfg. Part Number
- HM33-10040LFTR
- Manufacturer
- TT Electronics/BI
- Product Category
- Current Sense Transformers
- Brief Description
- CURRENT SENSE TRANSFORMERS
- Datasheet Download
- HM33-10040LFTR.pdf
Availability of HM33-10040LFTR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.03680
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HM33-10040LFTR, we specialize in TT Electronics/BI all series electronic components. HM33-10040LFTR can be shipped within 24 hours after order. If you have any demands for HM33-10040LFTR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HM33-10040LFTR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HM33-10040LFTR
| Internal Part Number | EIS-HM33-10040LFTR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Cert. of Compliance | |
| Standard Package | 750 | |
| Category | Transformers | |
| Family | Current Sense Transformers | |
| Series | HM33 | |
| Turns Ratio - Primary:Secondary | 1 : 40 | |
| Frequency | - | |
| Inductance | 320µH | |
| Current Rating | 10A | |
| DC Resistance (DCR) | 5 mOhm Primary, 1.35 Ohm Secondary | |
| E.T. | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 8.13mm L x 7.11mm W | |
| Height - Seated (Max) | 5.33mm | |
| Termination Style | Gull Wing | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HM33-10040LFTR | |
| Related Links | HM33-10, HM33-10040LFTR Datasheet, TT Electronics/BI Distributor | |
