Hirose Electric Co Ltd HR10A-10J-10S
- Mfg. Part Number
- HR10A-10J-10S
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Circular Connectors
- Brief Description
- HR10A, JACK, 10 POS W/SOCKET
- Datasheet Download
- HR10A-10J-10S.pdf
Availability of HR10A-10J-10S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HR10A-10J-10S, we specialize in Hirose Electric Co Ltd all series electronic components. HR10A-10J-10S can be shipped within 24 hours after order. If you have any demands for HR10A-10J-10S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HR10A-10J-10S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HR10A-10J-10S
| Internal Part Number | EIS-HR10A-10J-10S | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 20 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | HR10A | |
| Packaging | Bulk | |
| Connector Type | Jack, Female Sockets | |
| Number of Positions | 10 | |
| Shell Size - Insert | 10 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Solder | |
| Fastening Type | Push-Pull | |
| Orientation | Keyed | |
| Ingress Protection | - | |
| Shell Material, Finish | Brass and Zinc, Nickel Plated | |
| Contact Finish | Silver | |
| Features | - | |
| Contact Finish Thickness | - | |
| Current Rating | 2A | |
| Voltage - Rated | - | |
| Operating Temperature | -25°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HR10A-10J-10S | |
| Related Links | HR10A-, HR10A-10J-10S Datasheet, Hirose Electric Co Ltd Distributor | |
HR10A-10J-10S Details Description
