API Delevan HTPT66R-104K
- Mfg. Part Number
- HTPT66R-104K
- Manufacturer
- API Delevan
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 100UH 1.9A 145 MOHM TH
- Datasheet Download
- HTPT66R-104K.pdf
Availability of HTPT66R-104K
Available Quantity
5749 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.51200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HTPT66R-104K, we specialize in API Delevan all series electronic components. HTPT66R-104K can be shipped within 24 hours after order. If you have any demands for HTPT66R-104K, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HTPT66R-104K Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HTPT66R-104K
| Internal Part Number | EIS-HTPT66R-104K | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | High Temperature Power Toroids | |
| Standard Package | 100 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | HTPT66R | |
| Packaging | Bulk | |
| Type | Toroidal | |
| Material - Core | Iron | |
| Inductance | 100µH | |
| Tolerance | ±10% | |
| Current Rating | 1.9A | |
| Current - Saturation | 1.8A | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 145 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -55°C ~ 200°C | |
| Frequency - Test | 1kHz | |
| Mounting Type | Through Hole | |
| Package / Case | Radial | |
| Size / Dimension | 0.660" Dia x 0.360" W (16.76mm x 9.14mm) | |
| Height - Seated (Max) | - | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HTPT66R-104K | |
| Related Links | HTPT66, HTPT66R-104K Datasheet, API Delevan Distributor | |
