Vishay/Dale IHLP3232DZER330M5A
- Mfg. Part Number
- IHLP3232DZER330M5A
- Manufacturer
- Vishay/Dale
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 33UH 3.1A 159.43 MOHM
- Datasheet Download
- IHLP3232DZER330M5A.pdf
Availability of IHLP3232DZER330M5A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.88400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IHLP3232DZER330M5A, we specialize in Vishay/Dale all series electronic components. IHLP3232DZER330M5A can be shipped within 24 hours after order. If you have any demands for IHLP3232DZER330M5A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IHLP3232DZER330M5A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IHLP3232DZER330M5A
| Internal Part Number | EIS-IHLP3232DZER330M5A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | IHLP Inductor Series | |
| Video File | IHLP® Power Inductor Saturation Current Performance Test | |
| Featured Product | IHLP® Surface-Mount Power Inductors | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 500 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | Automotive, AEC-Q200, IHLP-3232DZ-5A | |
| Packaging | Tape & Reel (TR) | |
| Type | Molded | |
| Material - Core | - | |
| Inductance | 33µH | |
| Tolerance | ±20% | |
| Current Rating | 3.1A | |
| Current - Saturation | 3.2A | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 159.43 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | 6.1MHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.322" L x 0.322" W (8.18mm x 8.18mm) | |
| Height - Seated (Max) | 0.158" (4.00mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IHLP3232DZER330M5A | |
| Related Links | IHLP3232D, IHLP3232DZER330M5A Datasheet, Vishay/Dale Distributor | |
