NVE Corporation IL261-1E
- Mfg. Part Number
- IL261-1E
- Manufacturer
- NVE Corporation
- Product Category
- Digital Isolators
- Brief Description
- DGTL ISO 2.5KV GEN PURP 16QSOP
- Datasheet Download
- IL261-1E.pdf
Availability of IL261-1E
Available Quantity
5142 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.82400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IL261-1E, we specialize in NVE Corporation all series electronic components. IL261-1E can be shipped within 24 hours after order. If you have any demands for IL261-1E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IL261-1E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IL261-1E
| Internal Part Number | EIS-IL261-1E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | IsoLoop® Isolator | |
| Standard Package | 100 | |
| Category | Isolators | |
| Family | Digital Isolators | |
| Series | IsoLoop® | |
| Packaging | Tube | |
| Technology | GMR (Giant Magnetoresistive) | |
| Type | General Purpose | |
| Isolated Power | No | |
| Number of Channels | 5 | |
| Inputs - Side 1/Side 2 | 4/1 | |
| Channel Type | Unidirectional | |
| Voltage - Isolation | 2500Vrms | |
| Common Mode Transient Immunity (Min) | 30kV/µs | |
| Data Rate | 110Mbps | |
| Propagation Delay tpLH / tpHL (Max) | 15ns, 15ns | |
| Pulse Width Distortion (Max) | 3ns | |
| Rise / Fall Time (Typ) | 1ns, 1ns | |
| Voltage - Supply | 3 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 16-SSOP (0.154", 3.90mm Width) | |
| Supplier Device Package | 16-QSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IL261-1E | |
| Related Links | IL26, IL261-1E Datasheet, NVE Corporation Distributor | |
IL261-1E Details Description
