Vishay Semiconductor/Opto Division IL300-F-X017T
- Mfg. Part Number
- IL300-F-X017T
- Manufacturer
- Vishay Semiconductor/Opto Division
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Brief Description
- OPTOISO 5.3KV PHVOLT 8SMD
- Datasheet Download
- IL300-F-X017T.pdf
Availability of IL300-F-X017T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.71740
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IL300-F-X017T, we specialize in Vishay Semiconductor/Opto Division all series electronic components. IL300-F-X017T can be shipped within 24 hours after order. If you have any demands for IL300-F-X017T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IL300-F-X017T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IL300-F-X017T
| Internal Part Number | EIS-IL300-F-X017T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Isolators | |
| Family | Optoisolators - Transistor, Photovoltaic Output | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Channels | 1 | |
| Voltage - Isolation | 5300Vrms | |
| Current Transfer Ratio (Min) | - | |
| Current Transfer Ratio (Max) | - | |
| Turn On / Turn Off Time (Typ) | - | |
| Rise / Fall Time (Typ) | 1µs, 1µs | |
| Input Type | DC | |
| Output Type | Photovoltaic, Linearized | |
| Voltage - Output (Max) | 500mV | |
| Current - Output / Channel | 70µA (Typ) | |
| Voltage - Forward (Vf) (Typ) | 1.25V | |
| Current - DC Forward (If) (Max) | 60mA | |
| Vce Saturation (Max) | - | |
| Operating Temperature | -55°C ~ 100°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SMD, Gull Wing | |
| Supplier Device Package | 8-SMD | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IL300-F-X017T | |
| Related Links | IL300-, IL300-F-X017T Datasheet, Vishay Semiconductor/Opto Division Distributor | |
IL300-F-X017T Details Description
