Vishay/Dale IMC0402ER4N7S
- Mfg. Part Number
- IMC0402ER4N7S
- Manufacturer
- Vishay/Dale
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 4.7NH 360MA 170 MOHM
- Datasheet Download
- IMC0402ER4N7S.pdf
Availability of IMC0402ER4N7S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IMC0402ER4N7S, we specialize in Vishay/Dale all series electronic components. IMC0402ER4N7S can be shipped within 24 hours after order. If you have any demands for IMC0402ER4N7S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IMC0402ER4N7S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IMC0402ER4N7S
| Internal Part Number | EIS-IMC0402ER4N7S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | IMC0402_IMC0603 Obs 8/June/2015 | |
| PCN Other | M-0402/0603/0805 Series 02/Oct/2015 | |
| Standard Package | 10,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | IMC-0402 | |
| Packaging | Tape & Reel (TR) | |
| Type | - | |
| Material - Core | Ceramic | |
| Inductance | 4.7nH | |
| Tolerance | ±0.3nH | |
| Current Rating | 360mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 170 mOhm Max | |
| Q @ Freq | 20 @ 800MHz | |
| Frequency - Self Resonant | 4.8GHz | |
| Operating Temperature | -40°C ~ 100°C | |
| Frequency - Test | 100MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 0402 (1005 Metric) | |
| Size / Dimension | 0.039" L x 0.022" W (1.00mm x 0.55mm) | |
| Height - Seated (Max) | 0.024" (0.60mm) | |
| Supplier Device Package | 0402 (1005 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IMC0402ER4N7S | |
| Related Links | IMC040, IMC0402ER4N7S Datasheet, Vishay/Dale Distributor | |
IMC0402ER4N7S Details Description
