NXP Semiconductors/Freescale Semiconductor, Inc. IP4286CZ6-TTY,125
- Mfg. Part Number
- IP4286CZ6-TTY,125
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 6TSSOP
- Datasheet Download
- IP4286CZ6-TTY,125.pdf
Availability of IP4286CZ6-TTY,125
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IP4286CZ6-TTY,125, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. IP4286CZ6-TTY,125 can be shipped within 24 hours after order. If you have any demands for IP4286CZ6-TTY,125, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IP4286CZ6-TTY,125 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IP4286CZ6-TTY,125
| Internal Part Number | EIS-IP4286CZ6-TTY,125 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 31/Dec/2011 | |
| PCN Design/Specification | Resin Hardener 02/Jul/2013 | |
| Standard Package | 3,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Steering (Rail to Rail) | |
| Unidirectional Channels | - | |
| Bidirectional Channels | 4 | |
| Voltage - Reverse Standoff (Typ) | - | |
| Voltage - Breakdown (Min) | 6V | |
| Voltage - Clamping (Max) @ Ipp | - | |
| Current - Peak Pulse (10/1000µs) | - | |
| Power - Peak Pulse | - | |
| Power Line Protection | Yes | |
| Applications | General Purpose | |
| Capacitance @ Frequency | - | |
| Operating Temperature | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 6-TSSOP, SC-88, SOT-363 | |
| Supplier Device Package | 6-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IP4286CZ6-TTY,125 | |
| Related Links | IP4286CZ, IP4286CZ6-TTY,125 Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
IP4286CZ6-TTY,125 Details Description
