International Rectifier (Infineon Technologies Americas Corp.) IRFL4105PBF
- Mfg. Part Number
- IRFL4105PBF
- Manufacturer
- International Rectifier (Infineon Technologies Americas Corp.)
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 55V 3.7A SOT223
- Datasheet Download
- IRFL4105PBF.pdf
Availability of IRFL4105PBF
Available Quantity
5837 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.32208
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IRFL4105PBF, we specialize in International Rectifier (Infineon Technologies Americas Corp.) all series electronic components. IRFL4105PBF can be shipped within 24 hours after order. If you have any demands for IRFL4105PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IRFL4105PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IRFL4105PBF
| Internal Part Number | EIS-IRFL4105PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | High Voltage Integrated Circuits (HVIC Gate Drivers) | |
| Design Resources | IRFL4105TR Saber Model IRFL4105TR Spice Model | |
| PCN Design/Specification | SOT-223 FET Wire 04/Jul/2013 SOT-223 Cu Wire 08/Oct/2013 | |
| PCN Packaging | Package Drawing Update 19/Aug/2015 | |
| Standard Package | 80 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | HEXFET® | |
| Packaging | Tube | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 55V | |
| Current - Continuous Drain (Id) @ 25°C | 3.7A (Ta) | |
| Rds On (Max) @ Id, Vgs | 45 mOhm @ 3.7A, 10V | |
| Vgs(th) (Max) @ Id | 4V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 35nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 660pF @ 25V | |
| Power - Max | 1W | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-261-4, TO-261AA | |
| Supplier Device Package | SOT-223 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IRFL4105PBF | |
| Related Links | IRFL4, IRFL4105PBF Datasheet, International Rectifier (Infineon Technologies Americas Corp.) Distributor | |
