Internal Part Number | EIS-IRGS6B60KTRLPBF | |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
Production Status (Lifecycle) | In Production | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | IGBT Primer Device and Applications High Voltage Integrated Circuits (HVIC Gate Drivers) | |
PCN Assembly/Origin | Assembly Site Addition 10/Jul/2015 | |
PCN Packaging | Package Drawing Update 19/Aug/2015 | |
Standard Package | 800 | |
Category | Discrete Semiconductor Products | |
Family | IGBTs - Single | |
Series | - | |
Packaging | Tape & Reel (TR) | |
IGBT Type | NPT | |
Voltage - Collector Emitter Breakdown (Max) | 600V | |
Current - Collector (Ic) (Max) | 13A | |
Current - Collector Pulsed (Icm) | 26A | |
Vce(on) (Max) @ Vge, Ic | 2.2V @ 15V, 5A | |
Power - Max | 90W | |
Switching Energy | 110µJ (on), 135µJ (off) | |
Input Type | Standard | |
Gate Charge | 18.2nC | |
Td (on/off) @ 25°C | 25ns/215ns | |
Test Condition | 400V, 5A, 100 Ohm, 15V | |
Reverse Recovery Time (trr) | - | |
Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | |
Mounting Type | Surface Mount | |
Supplier Device Package | D2PAK | |
Weight | 0.001 KG | |
Application | Email for details | |
Alternative Part (Replacement) | IRGS6B60KTRLPBF | |
Related Links | IRGS6B6, IRGS6B60KTRLPBF Datasheet, International Rectifier (Infineon Technologies Americas Corp.) Distributor |
